Description

Custom-built power cable for designed for high-performance digital audio gear. OFHC copper power cable with premium Furutech connectors. The Furutech connectors, featuring 24k gold plating and α (Alpha) pure copper conductors. These connectors provide superior electrical contact and long-term reliability through their precision construction.

Cable Specs

• Cable Length 1.5 meters (4.92 feet)
• Conductor Material OFHC (Oxygen-Free High Conductivity) Copper
• Conductor Size 14 AWG
• Number of Conductors 3 + Shield
• Conductor Type Stranded
• Conductor Purity 99.99% pure copper
• Conductor Resistance (20°C) 2.28 Ω/1000 ft (typical for 14AWG)
• Shielding Type 100% Shielded
• Shielding Coverage Complete coverage around conductors
• Shield Drain Drained at wall side (single-point ground)

Connector Specs:

• Wall Connector Type – NEMA 5-15P Male Plug
• Wall Connector Model – Furutech FI-11M-N1(G)
• Wall Connector Plating – 24k Gold Plated
• Wall Connector Rating – 15A/125V AC
• Wall Connector Dimensions  – 48.2mm L × 38mm dia. × 74mm overall
• Wall Connector Cable Range – 6.6mm to 16.0mm diameter
• IEC Connector Type – IEC C13 Female
• IEC Connector Model –  Furutech FI-11(G)N1
• IEC Connector Plating –  24k Gold Plated
• IEC Connector Rating – 10A/250V, 15A/125V AC
• IEC Connector Dimensions  – 44.0mm L × 39.0mm dia. × 77.0mm overall
• IEC Connector Cable Range –  6.6mm to 16.0mm diameter
• Conductor Material α (Alpha) –  Pure Copper/Phosphor Bronze
• Ground System Earth (Ground) Jumper System
• Housing Material Nylon/Fiberglass front, Polycarbonate shell
• Clamp Type Metal cable clamp with stainless screws

Electrical Characteristics

The electrical performance of the power cable is optimized for low-noise, high-fidelity audio applications. The OFHC copper conductors provide 101% IACS conductivity compared to standard copper’s 100% rating, resulting in lower resistance and improved power delivery efficiency.

• DC Resistance (20°C) 2.28 Ω/1000 ft (14AWG OFHC)
• AC Resistance (typical) ~2.5 Ω/1000 ft (at 60Hz)
• Capacitance (core to core) ~120 nF/km (typical for 14AWG)
• Inductance (typical) ~0.2 μH/ft (typical)
• Impedance ~50-75 Ω (dependent on geometry)
• Conductor Conductivity 101% IACS (vs 100% for standard copper)
• Shielding Effectiveness >80dB EMI reduction (100% shield)
• Dielectric Strength >2000V AC
• Insulation Resistance >1000 MΩ·km
• Voltage Drop ~0.2V/100A·100ft (at rated current)
• Power Loss <1% at rated current
• Operating Temperature -20°C to +75°C
• Bend Radius 10× cable diameter (140mm minimum)
• Maximum Pull Tension 25 lbf (111 N)

Shielding Performance

The 100% shielding coverage on the power cable provides comprehensive protection against electromagnetic interference. The shield surrounds all three conductors and is drained at the wall side to prevent ground loops while maintaining effective EMI rejection.

The shielding effectiveness exceeds 80dB for most interference frequencies, with particular strength in the audio frequency range and switching power supply harmonics. This level of protection ensures that external electromagnetic fields from routers, wireless devices, and other digital equipment do not couple into your power lines and affect audio quality.

Connector Performance Features

Furutech connectors incorporate several advanced design features that enhance electrical performance and long-term reliability. The α (Alpha) pure copper conductors provide excellent electrical conductivity, while the 24k gold plating ensures corrosion resistance and stable contact resistance over time.

The Floating Field Damper System prevents induced magnetic fields that could create electromagnetic interference. The Earth (Ground) Jumper System ensures proper grounding continuity, while the metal cable clamps provide secure mechanical connection and resonance control.

Temperature and Environmental Ratings

The power cable operates reliably across a wide temperature range from -20°C to +75°C, making it suitable for various installation environments. The PVC jacket provides moisture resistance and UV protection, while the OFHC copper conductors maintain stable electrical characteristics across the operating temperature range.

The cable’s thermal stability ensures that resistance changes remain within ±0.1% across the full temperature range, providing consistent power delivery regardless of environmental conditions. This stability is particularly important for maintaining audio system performance as ambient temperatures vary.

Mechanical Specifications

The cable’s mechanical design balances flexibility with durability. The minimum bend radius of 10× cable diameter (140mm) prevents conductor damage during installation while maintaining the cable’s electrical characteristics. The stranded conductor construction provides flexibility for routing while maintaining current-carrying capacity.

The cable can withstand up to 10,000 flex cycles at the minimum bend radius, making it suitable for permanent installations where occasional movement may occur. The maximum pull tension of 25 lbf (111 N) ensures safe installation without conductor damage.

Installation and Safety Considerations

The power cable meets all applicable electrical codes and standards for 15-ampere circuits. The 14AWG copper conductors are rated for 15-ampere overcurrent protection per NEC requirements, ensuring safe operation in standard household electrical systems.

The single-point shield grounding at the wall side prevents ground loops while providing effective EMI protection. This grounding strategy is crucial for maintaining audio system performance and preventing interference coupling between equipment.

Quality Assurance and Testing

The  cable construction meets rigorous quality standards for professional audio applications. The OFHC copper conductors undergo purity testing to ensure 99.99% copper content, while the shielding effectiveness is verified through electromagnetic compatibility testing. The Furutech connectors are manufactured to precise tolerances and undergo quality control testing including contact resistance measurement, insulation testing, and mechanical durability verification. This comprehensive testing ensures consistent performance and long-term reliability.
